Mori Seiki NT4200/1000SZ CNC Multi-tasking Lathe For Sale - 2006
Brand
Category
Model
NT4200/1000SZ
Stock #
14491
Year
2006
Condition
Used
Location
Not specified
| CNC Control | yes |
| Type of CNC Control | Fanuc |
| # Axis | 9 |
| Swing | 28.7 inches |
| Turning Diameter | 25.9 inches |
| Turning Diameter Lower Turret | 13.7" |
| Center Distance | 42.5 inches |
| Bar Capacity | 2.5 inches |
| X Axis Travel | 29.5 inches |
| X2 Axis Travel | 7.7" |
| Y Axis Travel | 8.3 inches |
| Z Axis Travel | 44.1 inches |
| Z2 Axis Travel | 39.8" |
| B Axis Indexing | +/- 120° |
| C1/C2 Axis Index | 0.0001° |
| Spindle Nose | A2-6 |
| Spindle Speed | 5,000 rpm |
| Main Motor | 30 hp |
| Tailstock | no |
| Y Axis | yes |
| Live Tooling | yes |
| Milling Spindle Taper | Capto C6 |
| Live Tooling Speed | 12,000 rpm - Milling Spindle |
| Live Tooling Motor | 25 hp |
| Sub Spindle | yes |
| Sub Spindle Bar Capacity | 2.5 inches |
| Sub Spindle Nose | A2-6 |
| Sub Spindle Speed | 5,000 rpm |
| Sub Spindle Motor (HP) | 30 hp |
| Turret Capacity | 12 Stations Lower Turret |
| ATC Capacity | 100 Stations |
| Machine Weight | 49700 pounds |
|
- Fanuc CNC Control
- Chip Conveyor - Coolant Tank & Pump - Live Milling Spindle - Lower Turret with Live Tooling Capability - Sub Spindle - Y Axis - Hyd. Steady Rest on Lower Turret - 8" Chuck on Main Spindle - Collet Chuck on Sub Spindle - Probing - Coolant Thru Spindle - High Pressure - Chip Blaster Unit |
|
