15.74" (400 mm ) Saw blade
5.11" (130 mm) Cutting Diameter
5.11" (130 mm) Capacity 45 Degree: Round
6.29" x 35.0" (160 x 890 mm) Capacity 45 Degrees: Flat
5.11" (130 mm) Capacity 90 Degrees: Round
8.26" x 3.14" (210 x 80 mm) Capacity Degrees: Flat
3.54" (90 mm) Capacity 60 Degrees: Round
4.13" x 3.14" (105 x 80 mm) Capacity 60 Degrees: Flat
433/866 in/min (11/22 m/min) Cutting Speed
47.2" (1200 mm) Feed Length
141.7" (3600 mm) Multiple Feeding Length
2.14/3.35 HP (1.6/2.5 Kw) Power Capacity
150 Degrees Table Rotating
.629"-23.6" in/min (16-600 mm/min) Saw Blade-Feed Speed Stepless
16.73" (425 mm) Max Saw Blade Diameter
6.7 HP (5.0 Kw) Total Power Requirement
Description:
Mitre Cuts
Automatic Feed
Roll Guideways with Length Stop
As taken from service
