MODEL .......................... MS1140S TYPE ........................... MASCOTE SWING OVER WAYS ................ 14" SWING OVER CROSS SLIDE ......... 8" SWING IN GAP ................... 20" LENGTH OF GAP, FROM FACEPLATE .. 4-3/4" DISTANCE BETWEEN CENTERS ....... 40" CROSS SLIDE TRAVEL ............. 5-3/8" SPINDLE SPEEDS ................. (9) 50 TO 2000 RPM DIAMETER OF SPINDLE HOLE ....... 1-3/4" CHUCK .......................... 10" 3 JAW SPINDLE NOSE ................... D1-5" TAILSTOCK QUILL ................ 2" DIAMETER TAILSTOCK TAPER ................ #3 MT METRIC THREADS ................. (45) .2 TO 3.5 MM INCH THREADS ................... (32) 52 TO 3 TPI LONGITUDINAL FEEDS ............. .0015 TO .0427 IPR CROSS FEEDS .................... .0007 TO .0213 IPR HARDENED WAYS .................. YES COOLANT ........................ 1/8 HP MOTOR .......................... 5 HORSEPOWER |
