Swing Over Bed: 26"
Swing Over Cross Slide: 17.5" Swing in Gap: 35.1" Gap Width: 10.6" Distance Between Centers: 60" Bed Width: 15.7" Center Height: 42" Spindle Speeds: (12) 13 - 1200 RPM Spindle Motor: 15 HP Spindle Bore: 4-1/16" Spindle Taper and Center: MT-7 / MT-5 Spindle Nose: D1-11 Feed Ranges: 16 Longitudinal Feeds: 0.0012 - 0.039 Cross Feeds: 0.0004 - 0.0117 Leadscrew Diameter / Pitch: 1.77" / 4 Inch Threads: (44) 2 - 72 TPI Metric Threads: (39) 0.2 - 14 MM Compound Travel: 9" Cross Slide Travel: 15.8" Tailstock Quill Travel: 10" Tailstock Quill Diameter: 3.15" Tailstock Taper: MT-5 Coolant Pump Motor: 1/8 HP OAD (Approximate): 128" x 45" x 67" Weight (Approximate): 6490 Lbs. Note: All Specifications Subject to Verification Stock Machines Equipped with the Following Options:
|
