CAPACITY: WIRE DIAMETER................. .080" - .207"
WIRE LENGTH PER SPRING.................. 2.9" - 770"
COIL O.D. .............................. 3/8" - 3-3/4"
MOTOR................................... 10 HP 3/60-50/220-440 (1170-960 RPM)
O.A. DIMENSIONS ........................ 6'10" X 5' X 5'8" HIGH
WEIGHT ................................. 7,300 LBS.

EQUIPPED WITH:
5-ROLL & 7-ROLL 2-PLANE STRAIGHTENER
TORSION ATTACHMENT
REEVES VARI-DRIVE 580-1710 RPM
WITH 2 PALLETS PARTS - GEARS & STRAIGHTENER
10 HP 220/440 VOLT 3 PHASE 60/50 CYCLE
1170/960 RPM
WIRED FOR 220 VOLT
