MAXIMUM WIRE DIAMETER ................ .135" (3.43mm)
MINIMUM WIRE DIAMETER ................ .072" (1.83mm)

RATED CAPACITY: NO TURNS ............. 10
WIRE DIAMETER ........ .135" (3.43mm)

NO TURNS ............. 24
WIRE DIAMETER ........ .120" (3.05mm)

NO TURNS ............. 36
WIRE DIAMETER ........ .105" (2.67mm)

NO TURNS ............. 57
WIRE DIAMETER ........ .072" (1.63mm)

MAXIMUM SPINDLE TRAVEL ............... 4.500" (114.3mm)
SPRINGS PER MINUTE ................... 15 TO 75
WIRE FEED MAX ........................ 12" (305mm)
HORIZONTAL SLIDE TRAVEL .............. 1.500" (38.1mm)
VERTICAL SLIDE TRAVEL ................ 1.250" (31.8mm)
CAMSHAFT DIAMETER .................... 2.00" (50.8mm)
WIRE LINE HEIGHT ..................... 40" (1020mm)
DRIVE ................................ 3 HP
POWER REQUIREMENTS ................... 220/440 V, 50/60 Hz 3 PHASE
NET WEIGHT ........................... 4000 LBS
FLOOR SPACE .......................... 44" x 58.5" (1118mm x 1486mm)

EQUIPPED WITH: 7 ROLL 2 PLANE STRAIGHTENER

WITH MOTOR AND CONTROLS

OVERALL DIMENSIONS: 73" L x 46" W x 73" H
