CATALOG SPECIFICATIONS:
MAXIMUM CAPACITY (MILD STEEL) ..................... 10 GAGE CIRCLE DIAMETER FROM SQUARE BLANKS (MIN-MAX) ...... 6"-60" CIRCLE DIAMETER FROM OCTAGONAL BLANKS (MIN-MAX) ... 6"-78" SLITTING GAGE RANGE ............................... 7/8" - 17-1/4" THROAT, CUTTERS TO FRAME .......................... 18-1/2" THROAT OF CIRCLE ARM .............................. 43" DIAMETER OF CUTTERS ............................... 3" CIRCUMFERENTIAL SPEED OF CUTTERS .................. 100 FPM MAIN MOTOR: 3 HP 3/60/220-440V 1710 RPM WITH CONTROLS & FOOT PEDAL OPERATION FLOOR SPACE: 136" L-R x 20-1/2" F-B OVERALL DIMENSIONS: 9'10"L x 1'8"W x 4'8"H SHIPPING WEIGHT: (APPROX.) 2,000 LBS. |
