Longest Cone Distance | 11" |
Largest Pitch Angle | 90° |
Smallest Pitch Angle (without chamfering or burring attachments) | 45° |
Largest Pitch Diameter:-1 to 1 Ratio | 15.5" |
Largest Pitch Diameter:-12 to 1 Ratio | 22" |
Largest Pitch (diametral) | 1.5 DP |
Maximum Face Width | 4" |
Index Range(number of teeth) | 31-78 |
Feed (seconds per tooth) | 5-40 |
Diameter of Tapered Nose (large end) | 6-7/8" |
Length of Tapered Nose | .75" |
Taper Per Foot | .5" |
Diameter of Hole Through | 2" |
Spindle Nose to Center Line of Machine | 4.5"-8" |
Cutter Diameter | 9", 12", 18" |
Cutter Speeds | 100-150 |
Main Motor | 10 HP, 1800 RPM |
Floor Space | 84" x 103" |
Weight | 18,500 lbs |
Hydraulic Clamping. Stock Dividers.
This machine is being offered cleaned, and cycled. It is being offered with a 30-Day Return Privilege and may be inspected under power. |
