Title: 130" (3,300mm) x 1"(25.4mm) Blohm & Voss API Spiral Pipe Mill with Hydrotester Our stock number: 114748
Type: Pipe Mills
Brand: No brand specified
Model: No model specified
Year: 1978
Message
Information

130" (3,300mm) x 1"(25.4mm) Blohm & Voss API Spiral Pipe Mill with Hydrotester Our stock number: 114748

Brand
Not specified
Model
Not specified
Stock #
114748
Year
1978
Condition
Used
Location
Not specified
Link to our website listing http://uen.hsix.com/q/webinv/005700=x,114748
130" (3,300mm) x 1"(25.4mm) Blohm & Voss API Spiral Pipe Mill with Hydrotester   Our stock number: 114748

130" (3,300mm) x 1"(25.4mm) Blohm & Voss API Spiral Pipe Mill with Hydrotester

and (2) Beveling Machines

Manufacturer: Blohm & Voss
Year: 1978
Diameter 16" to 130"
Wall 0.250" to 1.000"
Grade up to X80
Pipe Length 12.2 to 24.4 m
Upgrade 3 roll leveler on uncoiler (2008)
Upgrade of fly welding of coils (2011)
Upgrade 2 edge milling units (4 heads in total)
2 units PWS, 600 mm diameter head, 110 KW per head (2007)
Upgrade main driver motors and control
45 KW x 2 motors (2011)
n1 = 1470 rpm; n2 = 1.103 rpm, roll diameter 750 mm
Upgrade to add mid forming roll, PRD (2015)

Hydrotester
1980
Diameter 20" to 80"
Pipe length 9 to 25 m
Max pressure 3500 psi

(2) PRD Pipe End Beveling Machines
Year:1994
20" to 72" Diameter Pipe
Includes Tooling for 20", 24", 30", 36", 40", 42", 48", 65.5" and 72"
