Capacity .............................. .6" to 4.33" Steel
Carbide cap. Solid steel .............. .98" to 3"
Capacity cutting round tube ........... 5.12"
Square tube ........................... .6" to 4.33"
Carbide saw diameter .................. 360mm/ 14"
HSS saw diameter ...................... 420mm/16.5"
Saw head feed type .................... Hydraulic
Material feed one stroke .............. 24"
Shortest cut off (Part length) ........ .4"
Remnant length ........................ 3.3"
Blade speeds .......................... 12-120 RPM
Loading magazine ...................... Incline type
max bar length ........................ 20'
Main Saw motor ........................ 15 HP
Coolant tank capacity ................. 38 Gallons
Operating Dimensions .................. 305" x 84" x 76" High
Weight ................................ 7,850 Lbs. |
