SERIAL ............................. 1L-1403 MODEL .............................. 1L BOX COLUMN DEPTH OF THROAT .................... 10-1/2" DIAMETER OF SWING AWAY TABLE ....... 19" SPINDLE SPEEDS ..................... (9) 100 TO 2000 RPM SPINDLE FEEDS ...................... .004, .008, .014, .020 IPR SPINDLE TRAVEL ..................... 10" TAPER IN SPINDLE ................... #4 MT DIAMETER OF SPINDLE ................ 2-3/4" AREA OF BASE ....................... 20-1/2" X 17-1/2" TRAVEL OF HEAD ON COLUMN ........... 12" VERTICAL TRAVEL OF TABLE ........... 18" DISTANCE SPINDLE TO TABLE .......... 0" MINIMUM TO 30" MAXIMUM DISTANCE SPINDLE TO BASE ........... 32" MINIMUM TO 44" MAXIMUM FORWARD AND REVERSE ................ YES MOTOR .............................. 3 HORSEPOWER |
