TABLE SIZE: 67" X 15.7"
T-SLOTS: 3 (0.7" AT 3.5" CENTERS) TABLE LOAD CAPACITY: 1,760 LBS. TABLE SWIVEL: ±45 DEG. TABLE LONGITUDINAL TRAVEL: 35.4" MANUAL / 34.6" AUTO TABLE CROSS TRAVEL: 12.4" MANUAL / 11.8" AUTO TABLE VERTICAL TRAVEL: 14.96" MANUAL / 14.17" AUTO SPINDLE SPEEDS: (18) 30 - 1500 RPM SPINDLE MOTOR: 15 HP SPINDLE TAPER: ISO 50 TABLE CENTER TO COLUMN SURFACE: 10" - 22.4" HORIZONTAL SPINDLE AXIS TO TABLE: 1.2" - 16.1" SPINDLE AXIS TO RAM SURFACE: 7.48" RAM TRAVEL: 27.5" LONGITUDINAL FEEDS: (18) 0.925 - 46.5 IPM CROSS FEEDS: (18) 0.925 - 46.5 IPM VERTICAL FEEDS: (18) 0.315 - 15.5 IPM LONGITUDINAL / CROSS RAPID TRAVERSE: 90 IPM VERTICAL RAPID TRAVERSE: 30.3 IPM FEED MOTOR: 4 HP COOLANT MOTOR: 0.17 HP OAD (APPROXIMATE): 101" X 85" X 70" HIGH WEIGHT (APPROXIMATE): 8,470 LBS. EQUIPPED WITH: 3-AXIS DRO HORIZONTAL SPINDLE WITH ARBOR SUPPORT POWER FEEDS ALL AXES UNIVERSAL SWIVELING TABLE COOLANT PUMP AND PIPING |
