One New U-Queen Bi Metal Forming Machine ... Price alone $65,365.00

0.7-3mm Wire Diameter
0.5-5mm Ag Cutoff Length
1.5-10mm Cutoff Length
2-7mm KO Length
90-150 Output ( free run/min)
Main Motor : 3HP 6 Phase

Optional with Machine:
PH-HUI05-PKO BM05 PKO System...$2,200
PH-HUI05-DDKO BM05 DDKO System ...$2,800
PH-HUI05-COL BM05 Catcher System...$2,800
PH-W60 Wire Stand 60 KG...$2,400
PH-CE Standard Safety ( complies with CE Regulations)...$8,940
Die-BM05 Machine Mold ...$1,500
Die-Design ...$1,165
BM05 Die Test ...Order  with Machine free of Charge $0.0
Box-05A BM05 Wooden Case ...$415

Machine Total with Options...$87,585.00

*** payment would be as follows: 30% down payment and 70% balance due by TT in advance, see details below***

1. Machine price includes: Pneumatic Brake, Inverter, PLC, Safety Cover, Defect Separation System, Basic Wire Stand, Auto Checker, Tool Set and Operation Manual.

2. Safety Level: Basic Safety- NC Brake, Double Loop Stop, Single Loop Micro Switch for Safety Doors, Proximity Sensor for Flywheel Bar, Protective Shield for Jog Mode, DC Work Light, Three-Color Light, Two Hand Operating on Jog, Air and Oil Monitoring, Safety Stickers.

3. NOTE: PKO System, DDKO System, Catcher System, Round Plate, Auto Wire Stand would be required to install on new order, any add on after shipping may cost additional installation fees.

Optional Available Accessories: PKO System, DDKO System, Catcher System, Round Plate, Auto Wire Stand, EU Standard Safety

4. Shipping: FOB Taiwan
5. Delivery - 90 to 120 days after down payment received
6. Packing- None ( wooden case for less container load, pallet for full container load)

7. Payment Term- order established upon receiving 30% down payment.  Buyer complete acceptance at seller's factory and wire balance within 5 working days.
Seller should arrange shipping in 3-5 working days after receiving balance amount

8. Sampling: ( Drawing No)
a. seller provides standard product drawing for test, dismount before shipping.
b. buyer supplies product drawing only.  seller design, produce tooling, test and provide samples.  Charges on tool design, tooling making.
c. buyer supplies product drawing, tooling drawings.  seller produce tooling, test and provide samples.  charges on tooling making.
d. buyer supplies product drawing, tooling set.  seller test and provides samples.

9. Raw Materials & Wire: Header or Former buyer Supply 20kG (min) Raw Material for Test
10. Motor: Confirmed before PO ( example- 380V, 50 Hz)
11. Air Compressor is required to operate machine ( 7.52 CFM/Per Unit)

12. Note:
Any further modifications after confirmed PO may result in additional charges.  Seller is required to inform buyer for scheduling training and acceptance at seller's factory 10-12 working days before completion.  Subject matter provided by the seller does not conform to the consent of both parties, seller shall improve unconditionally.  If the buyer cancels the order without the consent of both parties, the deposit will not be refunded.

13. Training:
A seller is obligated to provide one free training course to the buyer's assigned trainees before machine ships off.  Training takes place at seller's factory.  If demand training at buyer's factory ; after machine ships off...should coordinate with seller's round trip schedule and provide necessary tools for training purposes.  Buyer can also request a more flexible time for training at buyers factory, however additional charges such as flights and accommodations will apply.

14. Please note that all the bank charges should be paid by the payer and goods remain the property of U Queen Machinery Company Ltd until payment is made in full.
