ACRA MODEL FRD900 RADIAL ARM DRILLING MACHINE

Brand
Model
FRD900
Stock #
15595
Year
Not specified
Condition
New
Location
Not specified

ACRA MODEL FRD900 RADIAL ARM DRILLING MACHINE

• Roller bearing at base is built around a double column that provides maximum rigidity and accuracy.
• Made in Taiwan

Specifications:
Drilling Capacity Steel:                                          1-1/2”
Drilling Capacity Cast Iron:                                    2”
Tapping Capacity Steel:                                         ¾”
Tapping Capacity Cast Iron:                                  1”
Boring Capacity Steel:                                           3”
Boring Capacity Cast Iron:                                     4-1/8”
Spindle Stroke:                                                      7-7/8”
Spindle Taper:                                                        MT#4
Spindle Speeds (6):                                                88-1,500 RPM
Spindle Feeds:                                                       0.02-0.006 IPR
Column Diameter:                                                 8-1/4”
Spindle to Column Center:                                    11-7/8” ~ 36-3/16”
Base to Spindle:                                                     11-2/32” ~ 43-3/4”
Horizontal Travel of Headstock:                             24-13/16”
Spindle Drive Motor:                                              2 HP
Arm Elevation Motor:                                             1 HP
Coolant Pump Motor:                                            1/8 HP
Voltage:                                                                   230/460V AC~3 Phase
Weight                                                                    2800 lbs
Dimensions                                                             62 × 32 × 81 in

Standard Equipment:
• Coolant System
• Box Table
• Work Light
• Emergency Stop
• Toolbox
• Manual & Parts List
