NEW 26" X 90" ACRA 2690ACH PRECISION GAP BED ENGINE LATHE

Capacity:                                   26″/35″ x 90″
Swing Over Bed:                       26″
Swing Over Cross Slide:           17-1/2″
Swing In Gap:                           35-1/8″
Distance Between Centers:      90″
Bed Width:                               15-3/4″
Spindle Nose:                           D1-11
Spindle Bore:                            4-1/16″
Taper of Spindle:                      MT NO.7 x MT NO.5
Spindle Speeds – Steps:           12
Spindle Speeds – Range:          13 ~ 1,200 RPM
Cross Slide Travel:                    15-3/4″
Compound Slide Travel:            9-1/2″
Inch Threads:                            2 ~ 72 TPI
Metric Threads:                        0.2 ~ 14 mm
Longitudinal Feeds:                  0.0012 ~ 0.039 in/rev
Cross Feeds:                             0.0004 ~ 0.0117 in/rev
Quill Diameter:                         2.935″
Quill Travel:                               7″
Quill Taper:                               MT NO.5
Spindle Drive Motor:                15 H.P.
Voltage:                                    230/460V AC/3 PH
Weight                                      7200 lbs

Standard Equipment:
MAIN MOTOR 15 HP
CENTER SLEEVE MT No. 5
DEAD CENTER MT NO. 5 X 2 PCs
LEVELING SCREW AND BLOCK
SERVICE KITS AND TOOL BOX
STEADY REST- 1-5/8″ -10″
DRIVE PLATE- 12″ FOR D1-11 ONLY
COOLANT SYSTEM
MULTI – POSITION LENGTH STOP
FOLLOW REST
FACE PLATE- 20″
3 JAW SCROLL CHUCK- 15″
4 JAW INDEPENDENT CHUCK- 20″
FULL LENGTH SPLASH GUARD
