9" X 16" ACRA MODEL UE-916 VERTICAL/HORIZONTAL STEP PULLEY METAL CUTTING BANDSAW

Acra’s UE-916 Combination Vertical/Horizontal Step Pulley Metal Cutting Bandsaw is robust and quite compact for its cutting capacities. It is suitable for use in fabrication workshops, engineering workshops and general factory use. The chassis and arm are stiff cast iron giving great strength and accuracy in the cut, whilst the welded steel base houses a coolant pump system and the electrical controls. The 1.5 HP motor drives the blade through a choice of 4 speeds for a wide range of cutting tasks.

The cutting bow has a hydraulic down feed control ram with a feed rate selection dial and lock off control mounted on the switch panel. A comprehensive guide system holds the blade securely so that accurate cuts are made every time. A blade tension indicator is part of the tension system for accurate tension setting. The vice has a clever setting latch plus the rear jaw can be swiveled for bevel cuts. Safety interlock switches prevent the machine being run whilst the blade access doors are open. Coolant is supplied to both sets of guides; the flow rates can be set using the lever valves. This is a well-engineered machine that will do the job every day. It features the following:

• Heavy Duty Cast Iron Construction.
• Quick Acting Vise With 90° To 45° Full Mitering.
• Blade Chip Brush, Safeguards.
• Low Voltage Control with Overload.
• Easily Cleaning Removable Chip Tray.
• Automatic Stop for Machine When Stock Is Exhausted.
• Efficient Coolant System with Built-In Tank and Pump.
• Smooth and Silent in Operation.
• Standard Coolant.
• Made in Taiwan.

Specifications:
Round (90 Degree):                                  9”
Rectangular (90 Degree):                         9” x 16”
Round (45 Degree):                                  7”
Rectangular (45 Degree):                         7” x 6”
Blade Speeds (4):                                      86-132-170-235 FPM
Blade Size:                                                1.06” x .035” x 119.5”
Motor:                                                      1-1/2 HP
Voltage:                                                    110/220V AC / 1 PH
Weight                                                      750 lbs
Standard Equipment:
• Coolant System
• Removable Chip Tray
• Automatic Stop
• Blade Chip Brush
• Quick Acting Vise
