MURATA MURATEC TWIN SPINDLE CNC CHUCKER MODEL MW-20

Brand

Murata

Category

Lathes & Turning Machines

Type

Lathes, Production

Model

MW-20

Stock #

25776

Year

1995

Condition

Used

Location

Not specified

Specifications
Files & Videos

Catalog Specifications:
Distance Between Spindles 17.6"
Max Swing 17.04"
Standard Chuck Size 8/10"
Max Workpiece Diameter - with loader 8"
Max Workpiece Diameter - w/o loader 14"
Max Workpiece Length - with loader 4.8"
Max Workpiece Length - w/o loader 6.8"
Number of Turret Stations 10
Stroke X-axis (radius) 7.6"
Stroke Z-axis 8.8"
Spindle Speeds 35 to 3500 RPM
Spindle Motor 15 KW/ 30 Min
Weight, Approx 15,400 Lbs.

Specifications subject to verfication by the buyer.

EQUIPED WITH:
Fanuc 16TT Control
(1) 8" 3-Jaw Chuck on RH Spindle
(1) Special Chuck on LH Spindle
Chip Conveyor
Robot Loader
Hand Held Pulse Generator
Operator and Service Manuals

No files or videos to display
