MACHINE# 13572

SPECIFICATIONS:

Manufacturer:                    SMS (Germany)
Type:                            4-HI 4 Stand Cold Rolling Mill
                                 With Auto-Flatness Control
Capacity:                        800,000 Tons Per Year
Year of Manufacture:             2006
Work Roll Size:
 Diameter:                       400mm - 450mm (15.7"- 17.7")
 Width:                          1950mm (77")
Backup Roll Size:
 Diameter:                       1150mm - 1250mm (45" - 49")
 Width:                          1750mm (69")
Material Thickness:              1.8mm ~ 5.0mm (.070" - 0.20")
Material Width:                  800mm ~ 1650mm (31.5" - 65")
Material Coil OD:                1000mm ~ 2200mm (39.3" - 86.6")
Material Coil ID:                610mm (24")
Material Coil Weight(t)          Max. 30
Production Thickness:            0.3mm ~ 2.5mm (0.012" - 0.10")
Mill Max Speed (m/min)           1350 m/min (4430 FPM)
Threading Speed(m/min)           30 m/mim (98 FPM)
Acceleration (m/min/S)           30 m/min/s (98 FPM/Sec.

Tension:
 Payoff (KN) @ Speed(mpm)        96 KN @ 550mpm Max. 8 KN Min
 Winder (KN) @ speed(mpm)        150 KN @ 1300mpm Max. 12.5 KN Min
Payoff Motor Power(KW)           650 KW
Winder Motor Power(KW)           3550 KW left and right
Mill Motor Power:
 Stand #1 (KW)                   1 X 6000KW
 Stand #2 (KW)                   1 X 6000KW
Max Seperating Force(KN)         22,000 KN Stand #1 & Stand #2
Work Roll Size:                  450mm-400mm X 1950mm (15.7"- 17.7" x 76")
Buckup Roll Size:                1250mm-1150mm X 1750mm (45.2"- 49" x 69")
Main Drive Controller (3300VAC)  ABB ACS6000
 - Variable Speed Variable Voltage
Xray Gauge                       IMS Germany
AFC                              Sundwig (Germany) 2 Shape Meter Roll
Automation                       Siemens PLC/Wincc by SMS
Year of Built                    2006
Year Line Stopped:               2017

 ** SPECIFICATIONS SUBJECT TO REVISIONS **

 ** SPECIFICATIONS SUBJECT TO VERIFICATION BY PURCHASER **

 ** PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE **
