3-3/8" (85mm) X 1-3/8" (35mm) BUHLER SINGLE STAND WIRE FLATTENING MILL (13634)

 MACHINE #13634

 MANUFACTURER:                     BUHLER & CO GmbH

 General data

 Roll diameter:                    85mm (3.350")
 Roll Width:                       35mm (1.377")

 Screwdowns:                       Powered

 Electric connection               480 v,
 Control voltage                   230 v
 Magnetic valves                   24 V, GS
 compressed air
 working speed                     0-120m/min
 working direction                 right to left

 Material data

 Material                          Ag with ceramic core, coppers & stainless
 Thickness:                        0,15mm (0.0059") mininium
                                   0,30mm (0.0118") maximium
 Width:                            2,50mm (0.1") minimum
                                   4,00mm (0.157") maximum
 Thickness tolerance:              ± 0,001mm (0.00004")
 Width tolerance:                  ± 0,05mm (0.002")

 Uncoiler
 Coil Weight:                      40 - 150 kg (88-330 lbs)
 Coil inside diameter:             224 - 940mm (8.8" - 37mm)
 Coil outside diameter:            355 - 1000mm (14" - 39.37")
 Coil width:                       160 - 500mm  (6.3" - 20")

 Taking-up device
 coil inside diameter:             min. 224mm (8.8")
 coil outside diameter:            max. 355mm (14")
 coil width:                       160mm (6.3")
 Power coil drive:                 30 kg (66 lbs)

 **Please note catalogue specifications**

 **Temporary Specifications Subject to Revisions**

 **PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE**

 **ALL SPECIFICATIONS ARE SUBJECT TO VERIFICATION BY PURCHASE**
