Table size

55” x 32” (1400mm x 800mm)

T-Slots

20 mm x7

Maximum Loading

4,400 lbs (2,000kgs)

Height From Ground

37” (926 mm)

X Axis Travel

78.7” (2000mm)

Y Axis Travel

55” (1400mm)

Z Axis Travel

47” (1200mm)

Distance Between Spindle Center to Working Table

0-55” (0-1400mm)

Distance Between Spindle Nose to Table Center

12-60” (300-1500mm)

X, Y, & Z 12 Steps Cutting Speed(60/50HZ)

28-875/23-730 mm/min

Z 12 Steps Boring Speed(60/50HZ)

0.028-0.875/0.023-0.73 mm/rev.

X, Y, & Z Rapid Speed(60/50HZ)

2800/2400 mm/min

Spindle motor

10HP x 4P(6P)

Spindle changing speed(60/50HZ)

45-1500(30-1000) RPM

Spindle taper

NT-50BT-50)

Spindle cycle lubrication motor

0.2kw x4P

Centralized lubrication motor

25w

Auto feed gear box motor

1.2kw x4P

Cutting coolant motor

0.1kw x4P

Transmission motor

1.5kw x4P

Machine Net weight

10,500 kgs

Floor space requirement

(4500mm x 4400mm)
